Name: Ultra Thin 0.05mm Self Bonding Wire Class 155 / 180 Enamled Copper
Brand: Tianjin Ruiyuan Electric Material Co,.Ltd
SKU: 0.05mm
Price: 24.06 USD
Availability: InStock

Ultra Thin 0.05mm Self Bonding Wire Class 155 / 180 Enamled Copper

Basic Information

Place of Origin:	China
Brand Name:	Ruiyuan
Certification:	UL/ISO9001/ISO14001/RoHS/Reach
Model Number:	0.05mm

Minimum Order Quantity:	5 kg
Price:	Negotiation
Packaging Details:	Carton
Delivery Time:	2-15 days
Payment Terms:	Negotiation
Supply Ability:	10Ton/week

Get Best Price Contact Now

Detail Information

Product Name:	Ultra Thin 0.05mm Class 155 / 180 Self Bonding Enamled Copper Wire	Thermal Rating:	155/180
Insulation Material:	Polyurethane	Diameter:	0.05mm
Conductor Material:	Copper	Key Word:	Ultra Thin 0.05mm Class 155 / 180 Self Bonding Enamled Copper Wire
Highlight:	ultra thin self bonding wire , class 155 self bonding wire , 0.05mm enamelled copper wire

Product Description

Ultra thin 0.05mm class 155 / 180 self bonding enamled copper wire

Rvyuan has a variety of selfbonding products, small quantities included, available right from stock. For more information on this please tell us.

Bonding method options: Hot air,Solvent and others.


			Name

			Ultra thin 0.05mm class 155 / 180 self bonding enamled copper wire

			Key word

			Enameled copper wire

			Insulationh

			Enamel

			Thermal rating

			155/180

			Diameter of the enameled copper wire

			0.05mm

			Type

			Ultra thin 0.05mm class 155 / 180 self bonding enamled copper wire

			Item

			Characteristics

			Test Standard

			Conclusion

			1

			Bare Wire Diameter

			0.05±0.002MM

			0.050

			2

			Overall Diameter

			≤0.081MM

			0.077

			3

			Conductor Resistance

			MAX: 9.528Ω/M

			8.754Ω/M

			4

			Breakdown voltage

			≥3000V

			4245V

			5

			Elongation

			MIN:12%

			21.6%

			6

			Solderability

			390± 5℃ 2 Secs No Slags

			OK

Ultra Thin 0.05mm Self Bonding Wire Class 155 / 180 Enamled Copper 0

Ultra Thin 0.05mm Self Bonding Wire Class 155 / 180 Enamled Copper 1

Ultra Thin 0.05mm Self Bonding Wire Class 155 / 180 Enamled Copper 2

Tag:

Ultra Thin 0.05mm Self Bonding Wire Class 155 / 180 Enamled Copper

ultra thin self bonding wire

class 155 self bonding wire

0.05mm enamelled copper wire

flat copper wire,

covered copper wire,

self solderable copper wire

Round Self Bonding Wire

0.02mm Self Bonding Wire

0.12mm Self Bonding Enameled Copper Wire

Gauge 35 AWG Enameled Copper Wire Self Adhesive Magnet Wire

AIW220 0.14mm Hot Wind Enameled Copper Wire for Electrical

AIW 0.14mm High Purity Copper Wire Insulated Enameled Solid

Class 220 High Temperature Enamel Insulated Copper Winding Wire 0.14mm

SWG 0.14mm Copper Coil Wire Winding Materials Enamel Insulated Solid IEC / JIS / NEMA 1000

Name	Ultra thin 0.05mm class 155 / 180 self bonding enamled copper wire
Key word	Enameled copper wire
Insulationh	Enamel
Thermal rating	155/180
Diameter of the enameled copper wire	0.05mm
Type	Ultra thin 0.05mm class 155 / 180 self bonding enamled copper wire

Item	Characteristics	Test Standard	Conclusion
1	Bare Wire Diameter	0.05±0.002MM	0.050
2	Overall Diameter	≤0.081MM	0.077
3	Conductor Resistance	MAX: 9.528Ω/M	8.754Ω/M
4	Breakdown voltage	≥3000V	4245V
5	Elongation	MIN:12%	21.6%
6	Solderability	390± 5℃ 2 Secs No Slags	OK
