| Place of Origin: | China |
|---|---|
| Brand Name: | Ruiyuan |
| Certification: | UL/ISO9001/ISO14001/RoHS/Reach |
| Model Number: | OCC |
| Minimum Order Quantity: | 1 kg |
| Price: | Negotiation |
| Packaging Details: | Carton |
| Delivery Time: | 2-15 days |
| Payment Terms: | Negotiation |
| Supply Ability: | 10Ton/week |
| Product Name: | Certificated Occ Silver Wire 4n 99.998% High Purity For High End Audio Devices | Thermal Rating: | 155 |
|---|---|---|---|
| Insulation Material: | Bare Copper Wire | Diameter: | 0.08mm |
| Conductor Material: | Copper | Key Word: | Certificated Occ Silver Wire 4n 99.998% High Purity For High End Audio Devices |
| High Light: | high purity occ silver wire,4n occ silver wire,audio devices 6n silver wire |
||
Certificated Occ Silver Wire 4n 99.998% High Purity For High End Audio Devices
Advantage: Stability: The enamelled wire process makes the circuit surface of the high-purity enameled sterling silver wire completely flat without inconsistent resistivity or defects. This ensures the stability of the line during long-term use, enabling high-quality, low-vibration sound transmission in various application scenarios.
|
Name |
Certificated Occ Silver Wire 4n 99.998% High Purity For High End Audio Devices |
|
Key word |
Certificated Occ Silver Wire 4n 99.998% High Purity For High End Audio Devices |
|
Thermal rating |
155 |
|
Diameter |
0.5mm |
| Item | Unit | Requirement | Test result | ||
| Max. |
Min.
|
Mean.
|
|||
|
Single Over-all Diamerter |
[mm] | Max 0.56 |
0.52 |
0.52 |
0.52 |
|
Twisting ditection |
[mm] | Min 0.008 |
0.01 |
0.015 |
0.0125 |
|
Twisting distance |
[mm] | 0.500±1 |
0.500 |
0.490 |
0.495 |
|
Conductor resistance |
[Ω/m] |
—— |
0.107 |
0.107 |
0.107 |
|
Pinhole (6m) |
[个] | Max. 5 |
0 |
0 |
0 |
|
Single wire Elongation |
[%] | Min. 20 |
32.94 |
32.94 |
32.94 |
|
Conductor resistance |
[gf] | Min. 3688 |
3716 |
3716 |
3716 |
|
Solderability |
[s] | Max. 2 |
OK |
||
