Soldering Self Bonding Enameled Copper Wire Electric Motor Winding Materials

Detail Information
Product Name: Electric Motor Winding Materials Enameled Copper Wire Thermal Rating: 155/180
Insulation Material: Polyurethane Diameter: 0.14mm
Conductor Material: Copper Key Word: Electric Motor Winding Materials Enameled Copper Wire
Highlight:

0.14 mm enameled copper wire

,

soldering self bonding enameled copper wire

,

ultra fine enamelled constantan wire


Product Description

Electric Motor Winding Materials Enameled Copper Wire



Application fields: Enamelled copper wire has a wide range of applications. In the electronics manufacturing industry, enamelled copper wires are usually used in important parts such as the connection of circuit boards and the winding of transmitting equipment. In the fields of aviation, aerospace, nuclear energy and other fields, enamelled copper wire is also an indispensable key component.



Item Requirements Test Data
    Sample 1 Sample 2 Sample 3
Conductor diameter(mm) 0.140±0.004mm 0.140 0.140 0.140
Coating thickness ≥ 0.011mm 0.0150 0.0160 0.0150
Overall dimention(mm) ≤0.159mm 0.1550 0.1560 0.1550
DC Resistance ≤1.153Ω/m 1.085 1.073 1.103
Elongation ≥19% 24 25 24
Breakdown Voltage ≥1600V 3163 3215 3163
Pinhole ≤5(faults)/5m 0 0 0
Cut-through 200℃ 2min No breakdown ok
Heat Shock 175±5℃/30min No cracks ok
Solderability 390± 5℃ 2 Sec No slags ok

Name

Electric Motor Winding Materials Enameled Copper Wire

Key word

Enameled copper wire

Insulation

Enamel

Thermal rating

155/180

Diameter

0.4mm

Type

Electric Motor Winding Materials Enameled Copper Wire
