Integrity Molded Inductor 0.22uh Chip Inductance Embeded Coil For Electronics

Basic Information
Place of Origin: China
Brand Name: Rvyuan
Certification: ISO9001/ISO14001/UL/SGS
Model Number: 0.4-13
Minimum Order Quantity: Different types with differet MOQ
Price: Negotiation
Packaging Details: Spool with carton
Delivery Time: 2-15 workding days
Payment Terms: Negotiation
Supply Ability: Satisfy your demand
Detail Information
Product Name: Integrity Mold Power Inductor For Electronics Inductance: 0.22uh
Certification: ISO/RoHS Material: Magnetic Powder
Coil: Embeded Current Range: 5A
Inductance Range: 0.1uh-100uh Temperature Rise: ≤40°C
Dielectric Strength: >150V Operating Temperature: -20 ° C ~ +85 ° C
High Light:

smd power inductor

,

molded inductor


Product Description

INTEGRITY MOLDED INDUCTOR 0.22 UH CHIP INDUCTANCE EMBEDED COIL FOR ELECTRONICS

Integrity high power ferrite chip power inductor is a new type of inductor that the coils are embedded in the soft magnetic powder. Due to its closed magnetic circuit structure and the variety of soft magnetic materials, it has many different characteristics from traditional inductors. The integrated powder inductor also has excellent magnetic performance stability and temperature stability. In the production process, there are other characteristics that are not self-contained by the materials, that is, good controllability and shape controllability. It can produce a variety of unique performance inductors by controlling and changing the production process of the powder.

Electrical characteristics:

1. Inductance range: 0.1uH~100uH

2. Rated current range: 0.2A~80AIDC)

3. Resistance between coil and powder: ≥150V

4. Temperature rise: ≤40°C

Mechanical characteristics: The impact, drop, and vibration test results are superior to conventional inductors.

Environmental characteristics: Storage temperature: -40 ° C ~ +125 ° C

Working temperature: -20 ° C ~ +85 ° C

Application:

Power supply, PC, servers, communication devices, compact power supply modules, others.

Integrity Molded Inductor 0.22uh Chip Inductance Embeded Coil For Electronics 0

Size:

Integrity Molded Inductor 0.22uh Chip Inductance Embeded Coil For Electronics 1

Type

A(mm)

B(mm)

C(mm)

D(mm)

E(mm)

0420

4.2±0.35

4.4±0.35

1.8±0.2

2.0±0.3

0.8±0.2

0520

5.2±0.35

5.4±0.35

1.8±0.2

2.0±0.3

1.0±0.3

0530

5.2±0.35

5.4±0.35

2.8±0.2

2.0±0.3

1.0±0.3

0630

6.6±0.35

6.95±0.35

2.8±0.2

3.0±0.3

1.6±0.3

0640

6.6±0.35

6.95±0.35

3.8±0.2

3.0±0.5

1.6±0.3

1040

10.0±0.35

10.85±0.35

3.8±0.2

3.0±0.5

2.0±0.5

1284

8.1±0.2

12.9±0.4

3.8±0.2

3.5±0.5

2.5±0.5

1335

12.8±0.2

13.5±0.4

3.3±0.2

3.5±0.5

2.5±0.5

1350

12.6±0.2

13.45±0.35

4.8±0.2

4.0±0.5

2.5±0.5

1360

12.6±0.2

13.45±0.35

5.8±0.2

4.0±0.5

2.5±0.5

Item

Integrity Inductor

TC inductor

APL1108P56

PG0200


Integrity Molded Inductor 0.22uh Chip Inductance Embeded Coil For Electronics 2

Integrity Molded Inductor 0.22uh Chip Inductance Embeded Coil For Electronics 3

Integrity Molded Inductor 0.22uh Chip Inductance Embeded Coil For Electronics 4

Integrity Molded Inductor 0.22uh Chip Inductance Embeded Coil For Electronics 5

saturation current

45A REF

35A REF

45A REF

36A REF

Magnetic saturation thermal sensitivity

low

low

Normal

High

Temp Class of magnet wire

IAILKN5@200C

2UEW @135C

HAW @ 200C

PEW @155C

Production mode

Full Auto

Semi Auto

Semi Auto

Semi Auto

Magnetic sound

null

Slight

Slight

Yes

RoHS

Comliant

Comliant

No

Comliant

Customer designed

Easy

Normal

Normal

Difficult

Process problem

Null

Turn to turn fault

Apperance, Higher temperature rise

Excessive glue,Higher temperature rise

Price

Medium

Low

Medium

High
