Name: 0.025mm 6N/7N High-purity Super Fine Insulated/Bare OCC Copper Wire for Audio
Brand: Tianjin Ruiyuan Electric Material Co,.Ltd
SKU: 0.025mm
Price: 24.06 USD
Availability: InStock

Detail Information

Conductor Material:	Copper 6N/7N	Diameter:	0.025mm
Insulation Material:	Enameled	Rated Voltage:	/
Application:	Audio	Conductor Type:	Solid
Type:	Insulated	Product Name:	OCC Copper Wire
Standard:	IEC/JIS/NEMA	Conductor:	OCC 6N/7NCopper
Solderability:	Yes	Packing:	Carton
Delivery Time:	7-10days	Feature:	Rapid Signal Transmission
MOQ:	5kg	Payment:	T/T, Paypal, Etc.
Highlight:	0.025mm OCC copper wire , 6N/7N insulated audio wire , high-purity bare copper wire

Product Description

High-Vacuum Continuous Casting Equipment

Our production begins with high-vacuum continuous casting equipment, ensuring exceptional purity and a uniform single-crystal structure in every OCC copper wire.

Production Process

From continuous casting to ultra-fine drawing, each stage is tightly controlled to preserve the integrity of the single-crystal copper structure.

Single Crystal Copper vs. OFC Copper Fracture Comparison

The fracture surfaces below illustrate the structural difference between single crystal copper and ordinary oxygen-free copper (OFC).

Single crystal copper fracture

OFC fracture

Surface Quality After Ultra-Fine Drawing

After being drawn into ultra-fine wire, single crystal copper maintains a smoother, more uniform surface than ordinary OFC copper.

Surface of single crystal copper after being drawn into ultra-fine wire

Surface of ordinary OFC after being drawn into ultra-fine wire

Mechanical Properties: Single Crystal Copper vs. Polycrystalline Copper

Sample	Tensile Strength (MPa)	Yield Strength (MPa)	Elongation (%)	Vickers Hardness (HV)	Reduction of Area (%)
Single Crystal Copper	128.31	83.23	48.32	65	55.56
OFC Copper	151.89	121.37	26	79	41.22

Multi-Scenario Applications

Our 0.025mm high-purity OCC copper wire is engineered for demanding audio environments, delivering reliable signal transmission across a wide range of installations.

High-end home theater systems
High-end HiFi audio systems
KTV wiring
Car audio systems
Multimedia audio-visual rooms
Cinemas and banquet halls
Lecture halls and multimedia classrooms
Gyms, hotels, and restaurants
Office meeting rooms
Concert and multi-channel sound systems

Company Profile

Ruiyuan was established in 2002 and has been focusing on different kinds of high-quality wires: enameled round copper wire, rectangular enameled copper triple insulated wire, silk covered Litz wire, OCC wire, and self-bonding wire.

All of our products are UL and RoHS certified, in line with industry standards including IEC60317, JIS C 3202, NEMA, and NW82. Ruiyuan has a heritage of innovation, along with advancements in enameled wire, our company has grown through an unwavering commitment to integrity, service, and responsiveness to our customers. We look forward to being your most trusted partner.

Frequently Asked Questions

1. Can I get a sample for testing before placing a bulk order?

Of course. Samples can be offered to you free of charge, but express costs should be undertaken by the buyer.

2. What is your lead time?

Small sample orders take 3–5 working days; large orders should be completed within 15 working days after order confirmation.

3. What are your trade terms?

EXW, CPT, FOB, CIF, DDU, and DDP are all acceptable.

4. What are your payment terms?

T/T, D/P, D/A, L/C, and PayPal.

5. What express services do you offer?

FedEx, DHL, TNT, and UPS with great discounts of up to 80%.
