Name: 44 Awg 0.050mm Enamelled Copper Wire Winding For Motor
Brand: Tianjin Ruiyuan Electric Material Co,.Ltd
SKU: 0.05mm
Price: 24.06 USD
Availability: InStock

Detail Information

Product Name:	44 AWG Gauge 0.050mm Copper Winding Enamelled Wire For Motor	Thermal Rating:	155/180
Insulation Material:	Amide Imide	Diameter:	0.05mm
Conductor Material:	Copper	Key Word:	44 AWG Gauge 0.050mm Copper Winding Enamelled Wire For Motor
Highlight:	44 awg enamelled copper wire , 0.050 mm enamelled copper wire , motor super enameled copper winding wire

Product Description

44 AWG Gauge 0.050mm Copper Winding Enamelled Wire For Motor

we provide high quality enameled copper wire, size range from 0.011mm-1.2mm.

Features and advantages:

1.Solid enough, the wire is not easy to be broken
2.Insulation thickness can be customized
3.Wire can reach almost 0 pinhole
4.High consistency
5.The wire is even and tidy, which is convenient for users to wind
6. Low temperature soldering
7. Bonding method options: Hot air,Solvent and others


			Name
			44 AWG Gauge 0.050mm Copper Winding Enamelled Wire For Motor

			Key word
			Enameled copper wire

			Insulationh
			Enamel

			Thermal rating
			155/180

			Diameter of the enameled copper wire
			0.05mm

			Type
			44 AWG Gauge 0.050mm Copper Winding Enamelled Wire For Motor

			Item

			Characteristics

			Test Standard

			Conclusion

			1

			Bare Wire Diameter

			0.05±0.002MM

			0.050

			2

			Overall Diameter

			≤0.081MM

			0.077

			3

			Conductor Resistance

			MAX: 9.528Ω/M

			8.754Ω/M

			4

			Breakdown voltage

			≥3000V

			4245V

			5

			Elongation

			MIN:12%

			21.6%

			6

			Solderability

			390± 5℃ 2 Secs No Slags

			OK

			Conclusion

			Qualified

44 Awg 0.050mm Enamelled Copper Wire Winding For Motor

Tag:

Place of Origin:	China
Brand Name:	Ruiyuan
Certification:	UL/ISO9001/ISO14001/RoHS/Reach
Model Number:	0.05mm

Minimum Order Quantity:	5 kg
Price:	Negotiation
Packaging Details:	Carton
Delivery Time:	2-15 days
Payment Terms:	Negotiation
Supply Ability:	10Ton/week

44 Awg 0.050mm Enamelled Copper Wire Winding For Motor

44 awg enamelled copper wire

0.050 mm enamelled copper wire

motor super enameled copper winding wire

soft copper wire,

enameled copper magnet wire,

self solderable copper wire

Winding Coils Solderable Magnet Wire Blue / Green / Red / Brown Color

2UEW 155 0.02mm Enamelled Copper Wire

0.011mm Enameled Copper Winding Wire

0.045mm Polyurethane Enameled Magnet Wire

39 AWG 0.09mm 2UEW155 Magnet Winding Wire Enamel Insulated Copper Conductor

0.011mm 2UEW155 Enamel Coated Copper Wire For Motor Winding

Ruiyuan Super Thin Winding Coils Enameled Copper Wire 0.012mm-0.08mm

UEW-F Hot Wind Self Adhesive Self Bonding Enameled Copper Wire For Coils

Name	44 AWG Gauge 0.050mm Copper Winding Enamelled Wire For Motor
Key word	Enameled copper wire
Insulationh	Enamel
Thermal rating	155/180
Diameter of the enameled copper wire	0.05mm
Type	44 AWG Gauge 0.050mm Copper Winding Enamelled Wire For Motor

Item	Characteristics	Test Standard	Conclusion
1	Bare Wire Diameter	0.05±0.002MM	0.050
2	Overall Diameter	≤0.081MM	0.077
3	Conductor Resistance	MAX: 9.528Ω/M	8.754Ω/M
4	Breakdown voltage	≥3000V	4245V
5	Elongation	MIN:12%	21.6%
6	Solderability	390± 5℃ 2 Secs No Slags	OK
Conclusion		Qualified
