Nylon Serving Litz Wire 0.1mm*900 Silk Covered Wires For Transformer

Basic Information

Place of Origin:	China
Brand Name:	RVYUAN
Certification:	ISO9001/ISO14001 /UL/SGS
Model Number:	USTC

Minimum Order Quantity:	20kg
Price:	Negotiation
Packaging Details:	Spool with carton
Delivery Time:	15 workding days
Payment Terms:	T/T/ Paypal
Supply Ability:	Satisfy your demand

Get Best Price Contact Now

Detail Information

Diameter:	0.1mm	Temperature:	155
Certification:	IEC/NEMA/JIS/RoHS/ISO	Conductor:	Copper
Strands:	900	Breakdown Voltage:	Min.1100
Cover Material:	Nylon	Key Word:	Nylon Serving Litz Wire 0.1mm*900 Silk Covered Wires For Transformer
Highlight:	Nylon serving litz wire 0.1mm , Silk covered wires for transformer , 900 strand litz wire nylon

Product Description

Nylon Serving Litz Wire 0.1mm*900 Silk Covered Wires For Transformer

This specialized nylon serving Litz wire features 900 strands of 0.1mm silk-covered wires, engineered specifically for high-performance transformer applications.

Key Advantages

Multi-stranded construction significantly reduces AC resistance and eddy current losses
Ideal for high-efficiency transformers, inductors, and chokes operating at high frequencies
Nylon covering enhances surface lubricity for tighter, more uniform windings
Prevents damage to adjacent turns during winding processes
Superior flexibility and lower bending radius compared to solid wires
Easier installation in confined spaces and complex winding patterns

Technical Specifications

Item No.	Diameter of Single Wire (mm)	Conductor Diameter (mm)	OD (mm)	Resistance (Ω/m)	Breakdown Voltage (V)	Pitch
Tech Requirement	0.107-0.125	0.10±0.003	Max. 4.54	≤0.002646	≥1100	65±10
Sample 1	0.110-0.113	0.098-0.10	4.05-4.51	0.002393	2800	√

All specifications are subject to standard manufacturing tolerances. Contact us for detailed technical data sheets and custom requirements.
