Litz Wire 0.03mm-0.2mm USTC Silk Covered Stranded Copper Wire

Basic Information
Place of Origin: China
Brand Name: Ruiyuan
Certification: UL/ISO9001/ISO14001/RoHS/Reach
Model Number: USTCF litz wire
Minimum Order Quantity: 10kg
Price: Negotiation
Packaging Details: Carton
Delivery Time: 7 days
Payment Terms: TT/Paypal
Supply Ability: 100kg/week
Detail Information
Single Wire: 0.1mm Number Of Strands: 80
Jacket: Natural Silk Other Option Of Jackets: Polyester, Nylon
Conductor Material: Copper Key Word: Litz Wire 0.03mm-0.2mm USTC Silk Covered Stranded Copper Wire
Product Name: Litz Wire 0.03mm-0.2mm USTC Silk Covered Stranded Copper Wire
Highlight:

USTC Silk Covered Stranded Copper Wire

,

Litz Wire 0.03mm

,

Litz Wire 0.2mm


Product Description

Litz wire 0.03mm-0.2mm USTC Silk Covered Stranded Copper Wire

One of the standout features of our custom natural silk covered litz wire is that it is available in a wide range of colours, including an green as well as red and blue options. This not only enables you to enhance the performance of your audio equipment, but also tailor the aesthetics to suit your brand or personal preference.

Type

Conductor diameter*Strand number

2USTC-F 0.10*80



Single wire(strand)




Conductor diameter(mm) 0.100±0.003
overall diameter (mm) 0.107-0.125
Thermal Class(℃) 155



Strands construction




Strands number 80
Pitch(mm) 29±5
bunching direction S





Insulation layer




Material type Natural silk
Material specs(mm*mm or D) 300
Times of Wrapping 1
Overlap(%) or thickness(mm),mini 0.02
Wrapping direction S





Characteristics




Overall Diameter

Nominal (mm) 1.20
Max(mm) 1.28
Max pinholes Faults/6m 40
Max resistance (Ω/Km at20℃) 29.76
Breakdown voltage Mini (V) 1100
