Flat Enameled Copper Wire 4.0mm For Generator

Basic Information

Place of Origin:	China
Brand Name:	Rvyuan
Certification:	IEC/NEMA/JIS/RoHS/ISO
Model Number:	Class 220

Minimum Order Quantity:	Different types with differet MOQ
Price:	Negotiation
Packaging Details:	Spool with carton
Delivery Time:	2-15 workding days
Payment Terms:	Negotiation, T/T, L/C
Supply Ability:	Satisfy your demand

Get Best Price Contact Now

Detail Information

Item:	Flat Enameled Copper Wire 4.0mm For Generator	Width:	4.0mm
Product Name:	Flat Enameled Copper Wire 4.0mm For Generator	Product Category:	Rectangular Copper Wire
Applications:	Generator	Thickness:	0.2mm
Material:	Copper	Key Word:	Flat Enameled Copper Wire 4.0mm For Generator
Highlight:	Generator Flat Enameled Copper Wire , 4.0mm Flat Enameled Copper Wire , 4.0mm Enameled Copper Wire

Product Description

Flat Enameled Copper Wire 4.0mm For Generator

Ruiyuan's custom enameled flat copper wire is a versatile and reliable solution for a variety of industrial applications. With a commitment to customization and quality, we strive to meet the unique needs of our customers and provide them with the best solutions for their electrical and electronic requirements.

Item		Conductor dimension		Thickness Of Insulation		Overall dimension		Dielectric breakdown voltage	Pinhole	Conductor resistance
		Thickness	Width	Thickness	Width	Thickness	Width
Unit		mm	mm	mm	mm	mm	mm	kv	Pcs/m	Ω/km 20℃
SPEC	AVE	0.500	0.700	0.025	0.025	–	–
	Max	0.509	0.760	0.040	0.040	0.550	0.800		3	62.250
	Min	0.491	0.640	0.010	0.010	–	–	0.700
No. 1		0.494	0.711	0.024	0.022	0.541	0.755	2.310	0	53.461
No. 2		–	–	–	–	–	–	2.360
No. 3		–	–	–	–	–	–	2.201
No. 4		–	–	–	–	–	–	2.240
No. 5		–	–	–	–	–	–	2.056
Ave		0.494	0.711	0.024	0.022	0.541	0.755	2.233
Number of reading		1	1	1	1	1	1	5
Min. reading		0.494	0.711	0.024	0.022	0.541	0.755	2.056
Max. reading		0.494	0.711	0.024	0.022	0.541	0.755	2.360
Range		0.000	0.000	0.000	0.000	0.000	0.000	0.304
Result		OK	OK	OK	OK	OK	OK	OK	OK	OK
