| Place of Origin: | China |
|---|---|
| Brand Name: | Ruiyuan |
| Certification: | UL/ISO9001/ISO14001/RoHS/Reach |
| Model Number: | 0.11mm*0.26mm |
| Minimum Order Quantity: | 10kg |
| Price: | Negotiation |
| Packaging Details: | Carton |
| Delivery Time: | 2-15 days |
| Payment Terms: | Negotiation |
| Supply Ability: | 10Ton/week |
| Product Name: | AIW220 Flat Enameled Copper Wire Self Adhesive Wire | Thermal Rating: | 180/220 |
|---|---|---|---|
| Insulation Material: | Amide Imide | Width: | 0.11mm |
| Thickness: | 0.26mm | Conductor Material: | Copper |
| Key Word: | AIW220 Flat Enameled Copper Wire Self Adhesive Wire | ||
| High Light: | aiw220 super enamelled copper wire,self adhesive super enamelled copper wire,self bonding rectangular copper wire |
||
AIW220 flat enameled copper wire self adhesive wire
The self-adhesive flat copper enameled wire we produce adopts alcohol self-adhesive wire and hot air self-adhesive wire, which can meet the different needs of customers. Among them, the hot air self-adhesive thread is more environmentally friendly and has a wider range of applications.
| Size(mm) | Conductor Dimension(mm) | Thickness of single insulation(mm) | Bonding layer of single insulation(mm) | Overall dimension(mm) | Max. Conductor Resistance 20℃(Ω/km) | Breakdown voltage(kv) | Pinhole(pcs/m) | Elongation | Bonding strength | |||||||||||
| Width | Thickness | |||||||||||||||||||
| Width | Tolerance | Thickness | Tolerance | Width | Thickness | Width | Thickness | Min | Normal | Max | Min | Normal | Max | Min | Max | N/MM | ||||
| 0.11*0.26 | 0.260 | ±0.02 | 0.110 | ±0.004 | 0.005±0.015 | 0.0045±0.001 | 0.0025±0.001 | 0.0025±0.001 | 0.255 | 0.275 | 0.295 | 0.120 | 0.124 | 0.128 | 591.810 | 748.63 | 0.5 Min | 1Max. | 15 Min. | 0.29 |
Product name | AIW220 flat enameled copper wire self adhesive wire |
Coating material | AIW |
Thermal class | 220 |
Key word | AIW220 flat enameled copper wire self adhesive wire |
