0.08mm Class 155 Udtc Ustc Litz Wire Nylon Served Copper Stranded

Basic Information

Place of Origin:	China
Brand Name:	Rvyuan
Certification:	IEC/NEMA/JIS/RoHS/ISO
Model Number:	Copper litz wire

Minimum Order Quantity:	20kg
Price:	Negotiation
Packaging Details:	Spool with carton
Delivery Time:	2-15 workding days
Payment Terms:	Negotiation
Supply Ability:	Satisfy your demand

Get Best Price Contact Now

Detail Information

Name:	0.08mm Class 155 USTC / UDTC Nylon Served Copper Stranded Litz Wire	Certification:	ISO9001/ISO14001/UL/SGS
Diameter:	0.08mm	Standard:	GB/T5013.3/IEC60245-3:1994
Conductor:	Copper	Insulation:	Enamel
Rated Temperature:	155/180	Key Word:	0.08mm Class 155 USTC / UDTC Nylon Served Copper Stranded Litz Wire
No. Of Strands:	17
Highlight:	0.08mm ustc litz wire , class 155 ustc litz wire , stranded ustc wire

Product Description

0.08mm class 155 USTC / UDTC Nylon served copper stranded litz wire

Silk-covered wire refers to an electromagnetic wire made by wrapping natural silk or fiber silk (nylon, polyester fiber, natural silk, self-adhesive silk, etc.)

Our factory can customize various types of Litz wire, which is one of our company's main products and best-selling products,including silk covered wire, Mylar wire, etc.

Name	0.08mm class 155 USTC / UDTC Nylon served copper stranded litz wire
Key word	Copper litz wire
Insulationh	Enamel, polyster cover
Thermal rating	155degree
Diameter of the enameled copper wire	0.08mm
Number of strands	155 / 180
Type	0.08mm class 155 USTC / UDTC Nylon served copper stranded litz wire

Characteristics	Technical requests	Test Results
Conductor diameter(mm)	0.08±0.003	0.078	0.080
Overall conductor diameter(mm)	0.087-0.103	0.090	0.093
Maximum outer diameter(mm)	0.52	0.42	0.47
Pitch(mm)	27±3	√	√
Maximum Resistance(Ω/m 20℃)	0.2221	0.200	0.202
Minimum Breakdown Voltage(V)	1100	2700	2600
Solderability	390±5℃, 6s	√	√
Pinhole(faults/6m)	Max.20	3	2

0.08mm Class 155 Udtc Ustc Litz Wire Nylon Served Copper Stranded

0.08mm ustc litz wire

class 155 ustc litz wire

stranded ustc wire
