Copper Polyamideimide Flat Magnet Wire 0.18mm For Motor Winding

Basic Information
Place of Origin: China
Brand Name: Ruiyuan
Certification: UL/ISO9001/ISO14001/RoHS/Reach
Model Number: 0.3mm*0.18mm
Minimum Order Quantity: 5kg
Price: Negotiation
Packaging Details: Carton
Delivery Time: 2-15 days
Payment Terms: Negotiation
Supply Ability: 10Ton/week
Detail Information
Product Name: Rectangular Enameled Copper Wire Thermal Rating: 220
Insulation Material: AIW Width: 0.3mm
Thickness: 0.18mm Conductor Material: Copper
High Light:

polyamideimide flat magnet wire

,

flat magnet wire 0.18mm

,

polyamideimide flat copper wire


Product Description

Polyamideimide Flat Enamel Insulated Copper Wire For Motor Winding



Rectuangular or flat enameled copper wire consists two parts: width and thicness.When we describe the size, it likes thickness x width or width x thickness.



I know one side you need price as low as possible, but the other side you may worry about the quality, We are your best choice, because we have always provide cost effective but high quality product, Our wire has been used by Sumsung wireless charger, that passed crucial test. So don't worry about the quality





Characteristics
Standard
Test Result
Appearance
Smooth Equality
Smooth Equality
Conductor Diameter
Width
0.30
±0.050
0.300
Thickness
0.18
±0.050
0.180
Thickness of Insulation
Width
0.010±0.0050
0.011
Thickness
0.010±0.0050
0.008
Thickness of bonding layer   Min.0.002 0.003
Overall Diameter
(Including bonding layer)
Width
Max. 0.364
0.314
Thickness
Max. 0.219
0.191
Pinhole
Max ≤3hole/m

0
Elongation
Min ≥15 %

30%
Flexibility and Adherence
No crack

No crack
Conductor Resistance (Ω/km at 20℃)
Min.321.010
Max. 423.820
352.00
Breakdown Voltage
Min 050kv

1.65
Heat shock
No Crack

No Crack




Copper Polyamideimide Flat Magnet Wire 0.18mm For Motor Winding 0
