Enamel Coated Flat / Rectangular Copper Wire Magnet 0.04 - 1.3mm

Basic Information
Place of Origin: China
Brand Name: Ruiyuan
Certification: UL/ISO9001/ISO14001/RoHS/Reach
Model Number: 0.3mm*0.18mm
Minimum Order Quantity: 5kg
Price: Negotiation
Packaging Details: Carton
Delivery Time: 2-15 days
Payment Terms: Negotiation
Supply Ability: 10Ton/week
Detail Information
Product Name: Rectangular Enameled Copper Wire Thermal Rating: 220
Insulation Material: AIW Width: 0.3mm
Thickness: 0.18mm Conductor Material: Copper
High Light:

0.04mm rectangular copper wire

,

enamel coated rectangular copper wire

,

rectangular super enamel wire


Product Description

0.04 - 1.3mm Enamel Coated Flat / Rectangular Magnet Wire



1.Space: Electronics packaging continues to increase density. By nature of its shape, flat cable occupies roughly half the space of comparable round cable.

2.Weight: In addition to the reduction of unnecessary insulating, fillers and tapes, the composite flat-cable construction is so mechanically strong that it is not necessary to have large conductors for strength. The copper cross-section can thus be reduced to what’s required to carry the current load or to satisfy voltage-drop requirements.

3.Reduced Skewing Effects: Due to the conductors having the exact physical and electrical length, along with a continuous and consistent dielectric, time delays between signals within a given flat cable are minimized.





Characteristics
Standard
Test Result
Appearance
Smooth Equality
Smooth Equality
Conductor Diameter
Width
0.30
±0.050
0.300
Thickness
0.18
±0.050
0.180
Thickness of Insulation
Width
0.010±0.0050
0.011
Thickness
0.010±0.0050
0.008
Thickness of bonding layer   Min.0.002 0.003
Overall Diameter
(Including bonding layer)
Width
Max. 0.364
0.314
Thickness
Max. 0.219
0.191
Pinhole
Max ≤3hole/m

0
Elongation
Min ≥15 %

30%
Flexibility and Adherence
No crack

No crack
Conductor Resistance (Ω/km at 20℃)
Min.321.010
Max. 423.820
352.00
Breakdown Voltage
Min 050kv

1.65
Heat shock
No Crack

No Crack
