UL Certificated 2UEW 0.02mm Self Bonding Copper Wire For Voice Coils Hot Air

Basic Information
Place of Origin: China
Brand Name: Ruiyuan
Certification: UL/ISO9001/ISO14001/RoHS/Reach
Model Number: 0.02mm
Minimum Order Quantity: 20Kilogram/Kilograms
Price: Negotiation
Packaging Details: Carton
Delivery Time: 2-15 days
Payment Terms: Negotiation
Supply Ability: 10Ton/week
Detail Information
Product Name: Self Bonding Enameled Copper Wire Diameter: 0.02mm
Insulation: Polyurethane Bonding Method: Hot Air / Alcohol
Thermal Class: 155
High Light:

0.02mm Self Bonding Copper Wire

,

2UEW Self Bonding Copper Wire

,

2uew Self Bonding Magnet Wire


Product Description

UL Certificated 2UEW 0.02mm Self Bonding Enameled Copper Wire For Voice Coils Hot Air

We are one of the pioneers in producing micro thin enameled wires below 0.03mm in China. Our R & D team has 20 years of market experience.We have achieved the goal of "zero pinholes after stretching" for ten years.

We surpass them in terms of "service, quick response"; 30% lower "price" is our advantage.
Size range: 0.011mm-1.2mm

UL Certificated 2UEW 0.02mm Self Bonding Copper Wire For Voice Coils Hot Air 0
Characteristics
Technical requests
Test Results
Sample 1
Sample 2
Surface
Good
OK
OK
Bare Wire Diameter
0.020±0.001
0.02
0.02
Overall Diameter
0.022-0.024
0.023
0.023
Conductor Resistance
≤60.810Ω/m
56.812
56.403
Elongation
≥8%
10%
10%
Breakdown Voltage
≥130V
212
247
Pinhole Test
≤ 8 holes/5m
1
0
Test Items
Technical Requests

Results
Adhesive
Coating layer is good

OK
Cut-through
200℃ 2mins no breakdown

OK
Heat Shock
180±5℃/30min no crack

OK
Solder Ability
390± 5℃ 2 Sec Smooth

OK
Solvent Resistance
No blister, no expansion, no shed

OK
