| Place of Origin: | CHINA |
|---|---|
| Brand Name: | Rvyuan |
| Certification: | RoHS |
| Model Number: | EI28 |
| Minimum Order Quantity: | 1000pcs |
| Price: | 1.5-2USD |
| Packaging Details: | Carton |
| Delivery Time: | 2-15 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 2000000 Piece/Pieces per Month |
| Product Name: | Db-EI Encapsulated Transformer | Typical Value: | 0.36VA-1000VA |
|---|---|---|---|
| Mode: | EE/EI | Input Voltage: | AC100V 50/60Hz |
| Material: | Enamelled Copper Wire | Pin Quantity: | 3+3 |
| Output Voltage: | AC11.3V | Pin Array: | 7.5+7.5 |
| Highlight: | high frequency transformer,transformer ferrite core |
||
EI28 FERRITE CORE INDUCTORS 3mH HIGH FREQUENCY TRANSFORMER SWITCH MODE TRANSFORMER
This type of current transformer is fully insulated by epoxy resin. The primary winding is made of high quality copper bar or copper stripe. The secondary coils are wound by polyester enameled copper wires with high mechanical strength. We always choose raw material strictly before our production.
FEATURE
Compact,high solidity,high risistace,etc.Outpower is
Above 0.6VA to 1000VA.
| Item | Model | Dimension(mm) |
Export power Typical value |
| DB20-1 | EE20×6 | 22×23×15 | 0.35VA |
| DB20-2 | EE20×10 | 22×23×19 | 0.5VA |
| DB28-1 | EI28×15 | 30×27×28 | 0.5-1VA |
| DB30-01 | EI30×10.5 | 33×28×23 | 0.5-1VA |
| DB30-02 | EI30×12.5 | 33×28×25 | 1-1.5VA |
| DB30-03 | EI30×15.5 | 33×28×28 | 1.5-2.1VA |
| DB30-04 | EI30×18 | 33×28×31 | 2.1-3VA |
| DB35 | EI35×15 | 38×33×33 | 2-4VA |
| DB38 | EI38×13.5 | 56×46×38 | 4-5VA |
| DB | EI41×10 | 38×35×22 | 1.5-4VA |
| DB41 | EI41×14.5 | 42×28×32 | 5-8VA |
| DB54 | EI54×18 | 57×50×40 | 15-25VA |
| DB60 | EI60×30 | 68×56×58 | 20-40VA |
