99.99% 4N OCC Silver Litz Wire With Natural Silk Cover For Audio

Basic Information

Place of Origin:	China
Brand Name:	Ruiyuan
Certification:	UL/ISO9001/ISO14001/RoHS/Reach
Model Number:	OCC

Minimum Order Quantity:	2 kg
Price:	Negotiation
Packaging Details:	Carton
Delivery Time:	20days
Payment Terms:	Negotiation
Supply Ability:	10Ton/week

Get Best Price Contact Now

Detail Information

Product Name:	99.99% 4N OCC Silver Litz Wire With Natural Silk Cover For Audio	Conductor Diameter:	0.06mm
Conductor Material:	Silver	Key Word:	99.99% 4N OCC Silver Litz Wire With Natural Silk Cover For Audio
No. Of Strands:	24	Cover Material:	Natural Silk
Purity Level Of Silver:	99.99%
Highlight:	4N OCC silver litz wire , natural silk covered audio wire , high purity OCC wire

Product Description

99.99% 4N OCC Silver Litz Wire With Natural Silk Cover For Audio

This premium Litz wire features OCC (Ohno Continuous Casting) technology, ensuring exceptional purity and performance. The silver conductor boasts 99.99% purity, significantly exceeding the 92.5%, 99%, or 99.5% purity levels commonly found in standard silver wires. For applications requiring even higher purity, we offer a 99.999% high-purity silver option. This superior purity delivers enhanced conductivity and audio quality, making it an ideal choice for audiophile applications.

Technical Specifications

Item	Standard	Test Result
Surface	No crack, smooth	√
Single wire conductor (mm)	0.06±0.003	0.060
No. of strands	24	√
Pitch	8±2mm	√
Resistance	≤298.96Ω/km (20℃)	236.3
Breakdown voltage	≥0.95kV	1.2

The choice between pure silver wire and silver-plated copper wire depends on the user's budget, sound quality requirements, and specific application scenario.
