Name: 0.05mm 0.1mm Soft Silver Plated Copper Wire SPC
Brand: Tianjin Ruiyuan Electric Material Co,.Ltd
SKU: SPC
Price: 24.06 USD
Availability: InStock

Detail Information

Product Name:	High Quality 0.05mm Soft Silver Plated Copper Wire	Thermal Rating:	155
Insulation Material:	Enamel	Diameter:	0.05mm
Conductor Material:	Silver	Key Word:	High Quality 0.05mm Soft Silver Plated Copper Wire
Highlight:	0.05mm soft silver plated copper wire , 0.1mm SPC wire for crafts , OCC wire with silver plating

Product Description

0.05mm 0.1mm Soft Silver Plated Copper Wire SPC

Silver-plated copper wire is engineered for high-end audio applications, delivering superior conductivity and exceptional sound quality. Silver's enhanced conductivity compared to copper minimizes signal transmission loss, resulting in improved audio clarity and detailed sound reproduction.

This premium wire excels in high-frequency signal transmission, ensuring accurate reproduction of high-frequency audio components for enhanced overall sound performance. In professional audio equipment, silver-plated wire is the material of choice for connectors, speaker cables, and headphone wires, valued by audio enthusiasts and manufacturers for its combination of elegant appearance and superior electrical properties.

Key Applications

High-end audio connectors and interfaces
Premium speaker wire systems
Professional headphone cables
High-fidelity audio equipment manufacturing

Technical Specifications

Diameter (mm)	Tensile Strength (MPa)		Elongation (%)		Conductivity (IACS%)		Purity (%)
Diameter (mm)	Hard State	Soft State	Hard State	Soft State	Hard State	Soft State	Purity (%)
3.0	≥320	≥180	≥0.5	≥25	≥104	≥105	≥99.995
2.05	≥330	≥200	≥0.5	≥20	≥103.5	≥104	≥99.995
1.29	≥350	≥200	≥0.5	≥20	≥103.5	≥104	≥99.995
0.102	≥360	≥200	≥0.5	≥20	≥103.5	≥104	≥99.995

Tag:

Place of Origin:	China
Brand Name:	Ruiyuan
Certification:	UL/ISO9001/ISO14001/RoHS/Reach
Model Number:	SPC

Minimum Order Quantity:	2 kg
Price:	Negotiation
Packaging Details:	Carton
Delivery Time:	2-15 days
Payment Terms:	Negotiation
Supply Ability:	10Ton/week
