| Place of Origin: | China |
|---|---|
| Brand Name: | Ruiyuan |
| Certification: | UL/ISO9001/ISO14001/RoHS/Reach |
| Model Number: | 0.11mm*0.26mm |
| Minimum Order Quantity: | 10kg |
| Price: | Negotiation |
| Packaging Details: | Carton |
| Delivery Time: | 2-15 days |
| Payment Terms: | Negotiation |
| Supply Ability: | 10Ton/week |
| Product Name: | Super Thin Flat / Square Enameled Copper Wire For High Frequency Transformers | Thermal Rating: | 180/220 |
|---|---|---|---|
| Insulation Material: | Amide Imide | Width: | 0.11mm |
| Thickness: | 0.26mm | Conductor Material: | Copper |
| Key Word: | Super Thin Flat / Square Enameled Copper Wire For High Frequency Transformers | ||
| High Light: | super thin flat enameled copper wire,transformers flat enameled copper wire,soldering rectangular copper wire |
||
Super Thin flat / Square Enameled Copper Wire For High Frequency Transformers
The flat copper enameled wire we provide is a high-quality, high-performance wire material that is suitable for a variety of different application scenarios. If you want to find high-quality flat copper enameled wire as your wire material, please contact us, we will provide you with high-quality products and services.
| Size(mm) | Conductor Dimension(mm) | Thickness of single insulation(mm) | Bonding layer of single insulation(mm) | Overall dimension(mm) | Max. Conductor Resistance 20℃(Ω/km) | Breakdown voltage(kv) | Pinhole(pcs/m) | Elongation | Bonding strength |
|||||||||||
| Width | Thickness | |||||||||||||||||||
| Width | Tolerance | Thickness | Tolerance | Width | Thickness | Width | Thickness | Min | Normal | Max | Min | Normal | Max | Min | Max | N/MM | ||||
| 0.11*0.26 | 0.260 | ±0.02 | 0.110 | ±0.004 | 0.005±0.015 | 0.0045±0.001 | 0.0025±0.001 | 0.0025±0.001 | 0.255 | 0.275 | 0.295 | 0.120 | 0.124 | 0.128 | 591.810 | 748.63 | 0.5 Min | 1Max. | 15 Min. | 0.29 |
|
Product name |
Super Thin flat / Square Enameled Copper Wire For High Frequency Transformers |
|
Coating material |
AIW |
|
Thermal class |
220 |
|
Key word |
Super Thin flat / Square Enameled Copper Wire For High Frequency Transformers |
