| Place of Origin: | China |
|---|---|
| Brand Name: | Rvyuan |
| Certification: | IEC/NEMA/JIS/RoHS/ISO |
| Model Number: | 1.2x1.2mm |
| Minimum Order Quantity: | Different types with differet MOQ |
| Price: | Negotiation |
| Packaging Details: | Spool with carton |
| Delivery Time: | 2-15 workding days |
| Payment Terms: | Negotiation, T/T, L/C |
| Supply Ability: | Satisfy your demand |
| Insulation: | PEW/UEW/AIW | Diameter: | 1.2X1.2MM |
|---|---|---|---|
| Color: | Nature | Material: | Copper |
| Thermal Class: | 130/155/180/200/220 | Certificates: | ROHS/UL/SGS/ISO9001:2008 |
| Breakdown Voltage: | Over 3KV | OEM: | Yes |
| High Light: | served litz wire,soldering litz wire |
||
TRANSFORMER 1.2x1.2 MM COPPER LITZ WIRE STRANDED ENAMELED WIRE PROFILED LITZ WIRE NATURE COLOR
Profiled (mechanically shaped) litz wires allow optimal utilization of available winding area due to the superior filling factor of rectangular or square litz wire cross sections. In comparison to a standard round cross section construction, profiled litz wire can increase the filling factor by up to 20%.The design advantages of profiled litz wire can only be fully realized using products with consistent, precise dimensions. This dimensional stability is only possible with exact control over each process step.
FEATURES
Excellent bond strengths achieved by hot air bondind
Good memory behavior
Simplified and economical production of coils
Profiled dimensions to customer specification
Profiling also possible without any additional coatings
Dimensionally stable
APPLICATION
Induction coating hobs
RF transformers
RF transducers
E-Motors
SPECIFICATION
|
Smallest sizes (width x height) |
1.2 x 1.2 |
mm |
|
Ratio (width x height) |
01:01.7 |
mm |
|
Tolerance (±) |
0.1 |
mm |
|
Diameter of single wires |
0.020-0.500 |
mm |
