| Place of Origin: | China |
|---|---|
| Brand Name: | Rvyuan |
| Model Number: | TIW-B/F |
| Minimum Order Quantity: | 30,000 meters |
| Price: | Negotiation |
| Packaging Details: | Spool with carton |
| Delivery Time: | 2-15 workding days |
| Payment Terms: | Negotiation, T/T, L/C |
| Supply Ability: | Satisfy your demand |
| Certification: | VDE/RoHS/UL | Color: | Yellow |
|---|---|---|---|
| Size: | 0.15 | Packing: | Plastic Roll Then In Carton |
| Rated Temperature: | 130/155 | Solderability: | Directly |
| Conductor: | Copper | Solder Temperature: | 420-470 |
| High Light: | insulated copper wire,tiw wire |
||
DIRECTLY SOLDERABLE TRIPLE INSULATED WIRE THIN ENAMELED COPPER WIRE YELLOW COLOR 0.15MM
Ultra fine 0.15mm self solderable triple insulated wire is the product only rare manufacturer can provide, espeiclaly for class F/155. We may be the first provider who can produce 0.15mm class 155 with mass production in the world. That is better than Furukawa, this is not what we said but our customer in Europe.And our quality is similar to Furukawa, but price is much lower. We are the best choice for your enterprice.We also can provide self bonding or self adhesive triple insulated wire
FEATURE
Condutor size:0.15mm-1.0mm
Temperature Class:130/155
Working voltage:1000vms
Solder tempeature:420-470C
Breakdown voltage: Over 15KV
Complies with UL-2353,VDE IEC60950/61558 and CQC safety requirment
TEST REPORT
|
Characteristics |
Technical requests |
Test Results |
Conclusion |
||||||||
|
Sample 1 |
Sample 2 |
||||||||||
|
1 |
Surface |
Good |
OK |
OK |
OK |
||||||
|
2 |
Bare Wire Diameter |
0.15± |
0.008 |
0.155 |
0.15 |
OK |
|||||
|
0.008 |
|||||||||||
|
4 |
Overall Diameter |
0.35±0.02mm |
0.35 |
0.351 |
OK |
||||||
|
5 |
Conductor Resistance |
≤ 1008.70Ω/km |
988.5 |
979.6 |
OK |
||||||
|
6 |
Elongation |
≥ 15 % |
27.50% |
25.50% |
OK |
||||||
|
Remark: |
|||||||||||
|
|
Test Items |
Technical Requests |
Results |
Conclusion: |
|||||||
|
1 |
Adhesive |
Coating layer is good |
OK |
Approved |
|||||||
|
2 |
Heat Shock |
225 ℃ 30min no crack |
OK |
|
|
||||||
|
3 |
Solder Ability |
420± 5℃ 2-10 Secs |
OK |
|
|
||||||
|
4 |
Breakdown Voltage |
AC6KV/60s, no degumming, no crack |
OK |
||||||||
